But it's okay to leave those 4 pins disconnected because a motherboard with a 20 pin connector doesn't need them. The extra 4 pins were added to the 24 pin version of the cable to provide one extra wire for ground, 3.3, 5, and 12 volts. The 24 pin cable only fits into a 20 pin socket at one end so you can't plug it in incorrectly. The extra 4 pins on the cable just hang over the end of the motherboard connector. You can see an example in the picture above. If you have an ATX power supply with a 24 pin main cable, it's okay to plug it into a motherboard with a 20 pin connector. Unofficial cable/connector maximum wattage delivery for main rails Most newer power supplies don't provide -5 volts in which case the white wire is missing. Newer motherboards virtually never require -5 volts but many older motherboards do. The -5 volt line on pin 20 was made optional in ATX12V 1.3 (introduced in 2003) because -5 had been rarely used for years. These are pretty common on the 3.3 volt line in pin 13 but are sometimes used for other voltages too. Some of the voltage lines on the connector may have smaller sense wires which allow the power supply to sense what voltage is actually seen by the motherboard. The 24 pin connector is polarized so it can only be plugged in pointing in the correct direction. The extra pins made the auxiliary power cable unnecessary so most ATX12V 2.x power supplies don't have them.

The new 24 pin connector added one line apiece for ground, 3.3, 5, and 12 volts. The older 20 pin main power cable only has one 12 volt line.

The 24 pin main power connector was added in ATX12V 2.0 to provide extra power needed by PCI Express slots. Standard 4.2mm Pitch ATX Header Connector Datasheet
